Product Overview
Babcock Davis BNTC Architectural Access Door, 1″ Flange, *Concealed Spring Button Hinge, Screwdriver Cam Latch, White Powder Coat
*The concealed spring button hinge is for sizes < 24×24. Larger sizes provided with continuous flush piano hinge
Steel access doors allow access to mechanical, electrical, or plumbing fixtures inside or behind walls and ceilings. Designed for commercial use. Can easily be painted to match wall and ceiling colors. Constructed with an industry-standard 16 gauge steel door, the updated design provides superior strength and design aesthetics.
The Babcock-Davis Architectural Access Door is built with the architect in mind. Constructed with an industry-standard steel door, the design further improves on strength and aesthetics.
ANTI-FLEX FRAME Screws are inserted through our patent-pending Easy Install Tabs, firmly fitting the door to the wall without flexing the frame.
PAINLESS INSTALLATION When mounting screws are not required, quickly and easily install your new panel by bending our Easy Install Tabs over the drywall.
- Concealed spring pin hinge on sizes up to 24” x 24” – continuous flush piano hinge for sizes above
- Frame 16 gauge cold rolled steel
- Door 16 gauge cold rolled steel
- Flange 1” wide exposed
- Screwdriver cam latch
- Primer finish with baked-on rust inhibitor
- Rough opening 1/4” over
| Brand | |
|---|---|
| Fire Rating | None |
| Finish | White |
| Rough Opening Size | 1/4" Over |
| Material | 16 gauge Steel |
| Latch | Screwdriver Cam Latch |
| Hinge | Concealed spring button or Flush continuous piano |
| Flange | 1 inch Exposed |
| Pan Depth | 1/2 inch |
| Applications | Ceiling or Wall |
