Detex ECL-230D Alarm Panic Exit Control Lock

Usually Ships: 1-2 Business Days
  • Attack resistant design withstands over 2200 lbs. of outside pull force
  • 100 decibel alarm, powered by 9-volt battery (included)
  • Accepts standard rim cylinder (sold separately)

Available Options:

Clear

Detex ECL-230D UL-Listed Panic Hardware Exit Control Lock

The ECL-230 is a code-compliant, battery-alarmed, rugged dead bolt, panic device with steel plate and photo-luminescent sign providing managed security and a 100-decibel alarm for secondary exits.

  • Single-point deadbolt locking device, 1” throw
  • Attack-resistant design withstands over 2200 lbs. of outside pull force
  • Unauthorized pressing of exit bar emits high decibel, 100db alarm
  • Durable steel plate with photo luminescent sign absorbs light to then “glow in the dark” when lights are dimmed
  • Locking and unlocking the deadbolt always arms and disarms the alarm
  • Inside key control allows alarm bypass
  • UL listed panic hardware
  • 9-volt standard battery included
  • Rim cylinder required (sold separately)

made-in-usa

Brand

Finish

Black, Gray

ADA Compliance

Meets ADA requirements – A117.1 Accessibility Code

Door Thickness

1-3/4" to 2-1/4"

Handing

Non-Handed

Deadbolt

Single point – 1" throw, saw resistant

Cylinder

1-1/8" Rim Cylinder (Sold Separately)

Door Width

Minimum 20″, maximum 36″

Detex ECL-230D Installation Instructions
