DB1000SCT626KDC

Dexter DB1000-SCT Single Cylinder Deadbolt

Usually Ships: 1-2 Business Days
  • Heavy Duty – ANSI Grade 1
  • Single Cylinder x Inside Turn
  • Schlage C Keyway

Available Options:

Product Overview

Dexter ED1000-SCT Grade 1 Single Cylinder Deadbolt, 2-3/8″ or 2-3/4″ Adjustable Backset, Conventional Cylinder

Single cylinder x thumbturn

  • Grade 1, UL listed 3-hour
  • 1 3⁄8″ – 1 7⁄8″ Conventional cylinder door range; 1 5⁄8″ – 2″ SFIC door range
  • All functions include 2 3⁄8″ – 2 3⁄4″ universal square corner latch (30-253) and 1 1⁄8″ x 2 3⁄4″ square corner lipless strike
  • Accommodates Schlage conventional 6-pin (keyed 6) in Schlage C keyway, keyed different
Brand

Finishes

613 Oil Rubbed Bronze, 626 Satin Chrome
Deadbolt Type

Single Cylinder
ANSI Grade

ANSI A156.5 Grade-1
Usage

Heavy Duty
Cylinder & Keys

6-pin conventional, keyed different, with 2 keys
Keyway

Schlage C Keyway
Backset

2-3/8" to 2-3/4" Adjustable
Strike

1-1/8” x 2-3/4“ square corner
ADA Compliance

Meets ADA requirements – A117.1 Accessibility Code
Fire Rating

3 Hour Fire-rated
