Product Overview
Falcon K301S Grade 1 Privacy Cylindrical Lock, Non-keyed, Dane Lever
High traffic, high abuse door openings demand a Grade 1 quality lock to keep doors secure. When quality and reliability are needed but cost is a concern, the certified ANSI/BHMA Grade 1 Falcon K Series can do the job. The Falcon K Series offers a quality product at a value price, and is backed by one of the best names in the business – Allegion.
ANSI Function F76 – Latch bolt by levers. Outside lever locked by push button in inside lever. Rotating inside lever or closing door releases push button. Emergency release in outside lever unlocks door.
- Clutching lever design allows the lever to move when locked without unlatching the door, preventing damage to the chassis
- Four through bolts for added strength
- Lever security caps to help prevent undesired lever removal and lever sag after continual use
- Manufactured to Allegion’s industry-leading quality standards
| Brand | |
|---|---|
| Finishes | 613 Oil Rubbed Bronze, 626 Satin Chrome |
| Lock Function | Privacy |
| Usage | Heavy Duty |
| ANSI/BHMA Standard | Meets ANSI/BHMA A156.2, Series 4000, Grade 1 |
| ADA Compliance | Meets ADA requirements – A117.1 Accessibility Code |
| Fire Rating | UL/cUL listed up to 3 Hours (A Label) – UL symbol on the latch front |
| Handing | Non-Handed |
| Door Thickness | 1-3/4" to 2-1/4" |
| Backset | 2-3/4" |
| Latch | 1/2" throw – 1-1/8" x 2-1/4" face |
| Strike | 4-7/8” x 1-1/4” ASA/ANSI strike with curved lip to meet ANSI A115.2 door frame preparation |
| Clutch Lever | Yes |
| Screws | Furnished with combination screws for use in wood or metal doors and frames. |
| Lever Design | D (Dane) |
| Warranty | 10 Years |
