Product Overview
Markar FS302 Heavy Duty Full Surface Pin & Barrel Continuous Hinge, Satin Stainless Steel
The Markar FS302 Series Full Surface Continuous Pin and Barrel Hinge is ideal for flush doors and can be used to repair and replace existing hinges on both fire-labeled and non-labeled doors that have very tight clearances, giving it a weather tight seal.
Features
- Stainless steel end pins
- Fasteners concealed by covers
- Covers are extruded aluminum
- For flush doors
Benefits
- Used to repair and replace existing hinges
- For both fire-labeled and non-labeled doors that have very tight clearances
- Provides a weather-tight seal
- Fire ratings up to and including 3 hours
Certifications
- UL 10C – Standard for Positive Pressure Fire Tests of Door Assemblies
- Warnock Hersey listing
- ANSI/BHMA Standard A156.26
| Brand | |
|---|---|
| Finish | Stainless Steel |
| Material | 304 Stainless Steel |
| Usage | Heavy Duty |
| ANSI/BHMA Standard | ANSI/BHMA Standard A156.26 Grade 1, ANSI/SDI 250.13 Certified |
| Fire Rating | UL 10C – Standard for Positive Pressure Fire Tests of Door Assemblies, Warnock Hersey Listing |
| Continuous Hinge Type | Full Surface |
| Buy American Act Compliance | Meets Buy Amercian Act – Made in USA |
