SQ314-32D

McKinney SQ314 – Square Barrel Three Knuckle Decorative Hinge

Usually Ships: 3-5 Business Days
  • Clean lines and a modern aesthetic
  • .177 standard weight, full mortise
  • 32D/630 satin stainless steel finish

Available Options:

Product Overview

McKinney SQ314 Full Mortise Standard Weight Square Barrel Three Knuckle Decorative Hinge, Square Corner, Satin Stainless Steel

The SQ314 non-handed, stainless steel three knuckle hinge is used with square edge doors only and are recommended for use on interior or exterior hollow metal and wood frame doors of average weight with average frequency.

  • For 1-3/4″ thick square edge doors only
  • Stainless steel material
  • Bearing contains anti-friction component
  • Three knuckle
  • 20-minute fire rating (wood core fire doors)
  • 3-hour fire rating (hollow metal or steel covered composite fire doors)
  • Suitable for both interior and exterior doors
  • Crisp, clean design makes a bold statement
  • Pairs with decorative levers and square trim set from Corbin Russwin or SARGENT
  • Suites with Rockwood pulls, coat hooks, and door stops
Brand

Finishes

US32D (630) Satin Stainless Steel
Size

4.5" x 4", 4.5" x 4.5"
Hinge Type

Full Mortise
Knuckles

Three
Bearings

Concealed Bearing
Material

Stainless Steel
Gauge

0.177
Usage

Medium Duty
ANSI/BHMA Standard

Meets ANSI/BHMA A156 .1
Fasteners

Packed with wood and metal screws
Fire Rating

3-hour fire rating (hollow metal or steel covered composite fire doors), 20-minute fire rating (wood core fire doors)
