McKinney TA2771 4.5″ Full Surface Hinge

Usually Ships: 3-5 Business Days
  • ANSI/BHMA A156.1
  • Standard weight, full surface
  • NFPA 80 Compliant

Available Options:

McKinney TA2771 4-1/2″ Steel Five Knuckle Standard Weight Full Surface Hinge

The TA2771 (steel) five knuckle standard weight bearing full surface hinge is reversible and recommended for use on average frequency and/or medium weight wood or metal doors in public buildings where there is medium traffic.

Features

  • May be used on channel iron jambs
  • Narrow leaf is applied to the surface of the jamb with machine screws, door leaf is applied to the surface of the door with thru bolts and grommet nuts
  • Packed with all machine screws and thru bolts and grommet nuts
  • Pin is held in place by an NRP set screw
  • Reversible

Benefits

  • Sits flush with the doors and frames with which they are used
  • Non-Removable Pin (NRP) ensures hinge is held in place and can’t be removed when door is closed
Brand

Finishes

600 Prime Coat, 652 Satin Chrome

Size

4.5"

Hinge Type

Full Surface

Gauge

0 .134

Knuckles

Five

Bearings

Oil Impregnated Bearing

Fasteners

Machine: 2 x 1/4-20, 1/2 x 12-24

ANSI/BHMA Standard

Meets ANSI/BHMA A156 .1

Fire Rating

Approved for NFPA 80 fire rated openings
