NGP (National Guard) RO75 ADA Compliant Interlocking Ramp – 15″ Wide x 1/4″ High with 1/2″ Offset

Usually Ships: 5-10 Business Days
  • 15″ wide x 1/4″ tall with 1/2″ offset
  • Overlaps the offset
  • ADA compliant, ICC/ANSI A117.1

Available Options:

Product Overview

National Guard Products (NGP) RO75 1/4″ H x 15″ W ADA Compliant Aluminum Interlocking Ramp

Complies with the slope and run required by ADA and ICC/ANSI A117.1

  • BHMA Certified to ANSI/BHMA A156.21 1,000 Lb. Load Tested
  • Aluminum alloy 6063, T5 temper
  • 15″ wide x 1/4″ tall with 1/2″ offset
  • Typical wall thickness .110
  • Weight: 2.56 lbs./ft.
  • #10 FH zinc-plated wood screws included
  • Mill finish (optional slip-resistant SIA finish)
  • Return Closed Ends available

This product is fabricated to order and is not returnable or refundable.

Brand

Finishes

Mill Finish Aluminum, SIA – “Slick It Ain't" Abrasive Slip Resistant Non-Skid Finish
Length

36", 48", 72", 96"
Width

15"
Height

1/4"
Fire Rating

Fire rated-UL10c
ADA Compliance

Meets ADA requirements – A117.1 Accessibility Code
Buy American Act Compliance

Meets Buy Amercian Act – Made in USA
