Pemko RS138 Full Mortise Continuous Gear Hinge for 1-3/8″ Thick Door

Usually Ships: 5-10 Business Days

Designed for 1-3/8″ thick doors
For doors weights up to 90 lbs.
Designed mainly for new door applications

Available Options:

Finish

Length

Clear

Quantity:

Pemko _RS138_ Full Mortise Continuous Gear Hinge for 1-3/8″ Thick Doors

The RS138 Series Full Mortise Residential Continuous Geared Hinge is designed mainly for new door and frame applications and are applied to conceal both leaves. This hinge features shorter leaves for thinner doors, particularly those that are 1-3/8″ thick with a weight limit up to 90 lbs.

Features

Standard duty
Designed for 1-3/8″ thick residential doors that weigh up to 90 lbs.
Applied to conceal both leaves for safety and security
Certain door and frame conditions may require an extra 1/32″-1/16″ clearance
12″ bearing space

Brand	Pemko
Continuous Hinge Type	Full Mortise (Concealed)
Finishes	C – Clear Anodized Aluminum, D – Dark Bronze Anodized Aluminum
Length	79" (for 6'8" door), 83" (for 7'0" door)
Material	Aluminum
Usage	Standard Duty
Door Applications	Metal or Wood Doors
Door Thickness	1-3/8"
Warranty	10 Years
Buy American Act Compliance	Meets Buy Amercian Act – Made in USA
