Securitron DSB Dual Sense Electrified Exit Bar

Securitron DSB Dual Sense Bar

The Dual Sense Bar (DSB) is for use on magnetically locked, non-fire-rated doors.

Dependable touch and mechanical release for superior safety and redundancy

The Dual Sense Bar (DSB) is for use on magnetically locked, non-fire-rated doors. Specifically designed to address the most current building and life safety codes, the DSB features two independent switch circuits to release the lock. Simply touching the bar or engaging its mechanical movement will allow free egress. For indoor use only, the DSB can be installed on metal, aluminum or wood doors of all types. Meets “no special tools or knowledge” requirements.

Standard Features

• Redundant switches
• Release triggered by either 1/8″ mechanical movement or reliable touch sense technology
• Resistant to interference from radio frequency or electromagnetic frequency and external impact/ bounce attempts
• All metal construction
• Can be field cut to fit nonstandard door widths
• 16 ft. [4.8m] 22 AWG 6 conductor cable and armored door cord included
• Resists electrostatic discharge up to 27,000 volts
• MagnaCare® lifetime replacement, no fault, no questions asked warranty

Optional Features

• EL ElectroLynx® ready
• I Illuminated via fiber optics

Certifications

• CAN/ULC-S533 Listed
• ANSI/UL 294 Listed
• CSA-C22.2 No. 205 Listed
• NFPA 101

Electrical

• Dual Sense Bar Only — 24 mA at 12 or 24 VDC
• Dual Sense Bar with Illumination — 44 mA at 12 or 24 VDC

Operating Temperature

• +32 to +120F [0 to +49C]
• Indoor use
