Product Overview
SELECT pin & barrel continuous hinges are built to handle abuse from high-traffic applications. They are applied to the surface on the edge of the frame and door. No machining or reinforcement is required.
- CORROSION-RESISTANT STAINLESS STEEL
- TEMPLATED HOLE PATTERN
- 3-HR. FIRE RATING
- STAINLESS STEEL PIN
Brand | |
---|---|
Length | 79" (for 6'8" door), 83" (for 7'0" door), 85" (for 7'2" Door), 95" (for 8'0" door) |
Finish | Stainless Steel |
Material | 14 gauge 304 stainless steel with 3/16" diameter 304 stainless pin. Long-life nylon medical bearings. |
Load / Frequency | For 1-3/4" doors, 48" wide (max.), weighing up to 400 pounds (medium-frequency) without frame or door reinforcement; up to 600 pounds (low-frequency) without frame or door reinforcement. |
ANSI/BHMA Standard | ANSI/BHMA A156.26-2006 Grade 1 |
Fire Rating | 3 Hour Fire-rated |
Continuous Hinge Type | Full Mortise (Concealed) |
Usage | Heavy Duty |
Buy American Act Compliance | Meets Buy Amercian Act – Made in USA |
