Select SL302 Heavy Duty Stainless Steel Pin & Barrel Full Surface Continuous Hinge

Usually Ships: 2-3 Business Days
  • Heavy Duty 14 gauge 304 Stainless Steel
  • Supports weights up to 600lbs
  • 3/16″ Pin & Barrel Continuous Hinge

Available Options:

Clear

Product Overview

Stainless steel. Tamper-resistant leaf covers. Flush mounted (no door inset). For 1-3/4″ doors weighing up to 600 lb., 48″ max. door width.

SL302 pin & barrel continuous hinges are BHMA Grade 1 certified.

  • CORROSION-RESISTANT STAINLESS STEEL
  • TEMPLATED HOLE PATTERN
  • 3-HR. FIRE RATING
  • STAINLESS STEEL PIN

Brand

Length

83" (for 7'0" door), 85" (for 7'2" Door), 95" (for 8'0" door)
Finish

Stainless Steel
Material

14 gauge 304 stainless steel with 3/16" diameter 304 stainless pin. Long-life nylon medical bearings.
Load / Frequency

For 1-3/4" doors, 48" wide (max.), weighing up to 400 pounds (medium-frequency) without frame or door reinforcement; up to 600 pounds (low-frequency) without frame or door reinforcement.
ANSI/BHMA Standard

ANSI/BHMA A156.26-2006 Grade 1
Fire Rating

3 Hour Fire-rated
Continuous Hinge Type

Full Surface
Usage

Heavy Duty
Buy American Act Compliance

Meets Buy Amercian Act – Made in USA
